Waltham Dials
37-Size Dials
Part #
Description
Price
Dial877 Waltham 37-size, small metal clock dial. Chapter ring is raised. $20.00
Dial841 Waltham 37-size, small metal clock dial. Chapter ring is raised. $20.00
Dial772

Waltham 37-size, small metal clock dial. Chapter ring is raised.

$20.00
18-Size Dials
Part #
Description
Price
Dial878

Waltham 18-size chronograph dial.

A few scattered hairlines.

$100.00
Dial1049

Waltham 18-size, double-sunk 24-hour dial. (Center is just pressed in.) For an open face model '83 with feet at 1.7, 21.7, 39.2.

Hands included.

A very light hairline below the denter hole.

$50.00
Dial1117

Waltham 18-size unfinished fancy dial. Appears to be for a model '92 based on the foot locations of 18.2, 38.8, 57.6. I test fit it on a '92 plate and it did fit.

Hairline going through the center.

$40.00
Dial866

Waltham 18-size, single-sunk (seconds bit is just pressed in) dial. For a hunting model '83 with feet at 16.7, 36.7, 54.2.

The choo-choo is an aftermarket application. Appears to be fired enamel.

$40.00
Dial1036

Waltham 18-size, single-sunk dial. For an open face model '83 with feet at 1.7, 21.7, 39.2.

A few light hairlines.

$10.00
Dial590

Waltham Chronometro Sol 18-size, double-sunk 24-hour dial. For an open face model '83 with feet at 1.7, 21.7, 39.2. 24-hour numbers are just applied after firing.

Perfect

$75.00
Dial805

Waltham single sunk (seconds bit is just pressed in) for an open face model '77 or '79 with feet at 1.7, 21.7, 39.2.

No hairlines. Chip outside the 55 minute mark.

$20.00
Dial704 Waltham 18-size model '57 dial. Pinned feet. $30.00
Dial845 Waltham 18-size (probably) model '57 Home grade dial. $20.00
Dial771

Waltham 18-size early double-sunk dial.

Nice condition except for the chip to the right of the seconds bit.

$15.00
Dial707

Waltham 18-size, single-sunk dial. For a hunting model with feet at 16.7, 36.7, 54.2.

Short hairline below the seconds bit.

$20.00
Dial1156 Waltham 18-size, single-sunk (seconds bit is just pressed in) dial. For a hunting model with feet at 16.7, 36.7, 54.2. This is marked "Waltham Mass." as is usually seen on export models. $15.00
Dial1003

Waltham 18-size, single-sunk (seconds bit is just pressed in) dial. For an open face model '83 with feet at 1.7, 21.7, 39.2.

Nice condition

$15.00
Dial551

Waltham 18-size, single-sunk dial. For an open face model '83 with feet at 1.7, 21.7, 39.2.

Chip at the 10 minute mark. No hairlines.

$35.00
Dial586

Waltham 18-size, single-sunk dial. For a hunting model with feet at 16.7, 36.7, 54.2.

Perfect



$40.00
Dial563

Waltham 18-size, double-sunk dial. For a hunting model with feet at 16.7, 36.7, 54.2.

Chip outside the seconds bit at the 22 second mark.

$30.00
Dial429

American Watch Co. 18-size, single-sunk dial. Dial feet at 13.0, 36.5, 54.2.

One light hairline.

$20.00
Dial359

American Watch Co. 18-size, single-sunk dial. Dial feet at 16.7, 36.7, 54.2.

Chip above the '12'.

$20.00
Dial686

American Watch Co. 18-size, single-sunk dial. Dial feet at 16.7, 36.7, 54.2.

A couple very light hairlines.

$15.00
Dial688

American Watch Co. 18-size, single-sunk dial. Dial feet at 16.7, 36.7, 54.2.

A couple very light hairlines.

$15.00
Dial518

American Watch Co. 18-size, single-sunk dial. Dial feet at 1.7, 21.7, 39.2.

One vertical hairline.

$15.00
Dial520

American Watch Co. 18-size, 24-hour, un-sunk dial. Dial feet at 16.7, 36.7, 54.2.

Hairline.

$15.00
Dial506

Waltham (or possibly Elgin) single sunk dial for John F. Beyerle of Reading. Dial feet at 16.7, 36.7, 54.2.

Hairlines.

$15.00
Dial991

Waltham single-sunk 18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

One cut foot.

$15.00
Dial434

Waltham single-sunk 18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

One light hairline.

$15.00
Dial973

Waltham single-sunk (seconds bit is just pressed in)18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

No hairlines

$15.00
Dial758

Waltham single-sunk 18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

One light hairline.

$10.00
Dial759

Waltham single-sunk 18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

Chip above the 12.

$10.00
Dial411

Waltham 18-size, single-sunk dial. Feet at 13, 36.8, 54.2.

Edge chip outside the '7'.

$30.00
Dial255

Waltham 18-size, double-sunk dial. For an open face model '83 with feet at 1.7, 21.7, 39.2.

Several hairlines in the outer chapter.

$20.00
Dial124

Waltham double-sunk (center is pressed in) 18s (44.8mm) model 1883 (hunting). Dial feet at 16.7, 36.7, 54.2.

There is a chip at the 27 minute mark. A hairline runs from this to the seconds bit. Another short hairline at the 29 minute mark.

$10.00
16-Size Dials
Part #
Description
Price
Dial777

Early American Watch Co. single sunk arabic numeral dial. Measures about a 16-size (41.95mm), but the dial feet are located where the 14-size feet should be: 19.2, 38.8, 58.8.

Some edge chipping. Seconds bit should be reglued as it is loose.

$40.00
Dial1062

Early Waltham 16-size unsunk dial. Dial feet at 19.2, 38.8, 58.8.

Some edge chipping at the 8 minute mark.

$20.00
Dial1126

Waltham single-sunk 'Premier' dial. Dial feet at 18.2, 38.8, 57.6. For a later 1908 model.

No chips or hairlines.

$25.00
Dial1148

Waltham single-sunk 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '99 or '08.

Hairline at top and below the '7'.

$10.00
Dial1097

Waltham single-sunk 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '99 or '08.

Hairline at the 19 minute mark.

$10.00
Dial1001

Waltham double-sunk (center section is just pressed in) 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '99 or '08.

One dial foot has been cut. Short light hairline at the 26 minute mark.

$20.00
Dial725

Waltham single-sunk 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '99 or '08.

Short light hairlines near the top.

$15.00
Dial245

Waltham (unmarked) single-sunk 16s (42.2mm) dial. Dial feet at 18.2, 38.8, 57.6. Model 60/68/72.

Perfect dial - no chips or hairlines.

$45.00
Dial778 Waltham single-sunk 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '99 or '08. $20.00
Dial279

Waltham single-sunk 16s (42.2mm) dial for a model '72. Dial feet at 18.2, 38.8, 57.6.

A couple of very faint hairlines.

$25.00
Dial093 Waltham single-sunk (seconds bit is just pressed in) 16s (42.2mm) 24-hour dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '88. $45.00
Dial1013

Waltham single-sunk (seconds bit is just pressed in) 16s dial. Dial feet at 18.2, 38.8, 57.6. Fits a model '88.

Fading between the '9' and '10'.

$15.00
Dial419

Waltham single-sunk 'Equity' dial.

No hairlines.

$15.00
Dial744

Waltham single-sunk 'Equity' dial.

No hairlines.

$15.00
Dial381

Waltham single-sunk 'Equity' dial.

No hairlines.

$15.00
14-Size Dials
Part #
Description
Price
Dial389 Waltham 14S chronograph dial. Some minor edge chips, otherwise very nice. $115.00
Dial1071 Waltham 14S chronograph dial. Edge chip at the top and some hairlines, but faces up decently. $50.00
Dial1109

Single sunk dial that fits earlier 14s models. Dial feet at 21.6, 39.0, 58.4.

Some edge chipping, otherwise nice.

$20.00
Dial1105 Single sunk dial that fits a 14s model 1897. $20.00
Dial756

Appears to be a dial for a later model with a 14s pillar plate.

Hairlines in the seconds bit and going out through the '8'.

$15.00
Dial1007

Appears to be a dial for a later model with a 14s pillar plate.

Some very light hairlines around the '7'.

$20.00
12-Size Dials
Part #
Description
Price
Dial1058 12s painted metal dial. $10.00
10-Size Dials
Part #
Description
Price
Dial416

American Watch Co. 10S 37.7mm single sunk dial.

No hairlines.

$25.00
8-Size Dials
Part #
Description
Price
6-Size Dials
Part #
Description
Price
Dial787 Waltham 6S conversion (no seconds bit) dial. Dial feet at 8.0, 25.5, 44.2 $20.00
Dial786 Waltham 6S dial. Dial feet at 12.1, 35.8, 55.0 $15.00
Dial369 Waltham 6s (34.4mm). Dial feet at 7.5, 25.5, 44.0. $15.00
Dial1106

Waltham 6S dial. Dial feet at 12.1, 35.8, 55.0

One hairline between the '7' and '8'.

$10.00
Dial747

Waltham 6S dial. Dial feet at 12.1, 35.8, 55.0

One light hairline at the top.

$10.00
Dial767

Waltham 6S dial. Dial feet at 12.1, 35.8, 55.0

Light hairline between '7' and '8'.

$10.00
Dial169 Waltham metal 6s (33.8mm) with no seconds bit to convert a model '90 hunting movement to open face. Dial feet at 20.8, 40.0, 57.1. $10.00
Dial658

Waltham 6S dial with painted decorations.

Hairline around the '7'.

$10.00
Dial405 Waltham metal 6s (33.8mm) conversion dial with raised gold numbers. $12.00
0-Size Dials (and smaller)
Part #
Description
Price
Dial119

Waltham 0s (28.8mm) model 1891. Dial feet at 11.5, 36.5, 55.0.

Hairline outside the '35' minute mark. Small chip at the top. Stain by the 10 second mark.

$7.00
Dial766

Waltham 0s (28.8mm) model 1891. Dial feet at 11.5, 36.5, 55.0.

Small chip outside the 27 minute mark.

$10.00
Wristwatch Dials
Part #
Description
Price
Dial261 Waltham wrist watch dial. 27.7mm x 24.4mm. $8.00
